What Custom TFT Display / Touchscreen Display options are available?

Rocktech offers semi-customization options including interface, FPC, backlight, touch panel, open frame, and cover glass customization.

How much does a custom TFT display or touchscreen cost?

Tooling charges (NRE) depend on the complexity and requirements of the customization project.

What is the lead time for custom TFT displays?

Standard lead time is 4 to 6 weeks after design confirmation. Expedited options may be available upon request.

What certifications do your displays have?

Our displays comply with ISO 9001, ISO 14001, RoHS, and REACH standards.

Custom TFT LCD Display & Touchscreen Display Solutions

Q: What is the minimum order quantity (MOQ)?

For custom projects, typical MOQ is 1,000 pieces per lot. However, Rocktech supports pilot run orders of smaller quantities for initial validation.

Q: How do you ensure quality control?

Rocktech performs strict quality checks including material inspection, in-process checks, functional testing, and 100% visual inspection before shipment.

Rocktech offers complete custom display solutions ranging from 3.5-inch to 15.6-inch TFT and touchscreen modules, tailored to your design, performance, and integration requirements.

We help you build the perfect display kit by combining TFT panels, touch panels, backlight modules, FPC routing, cover glass, and bonding technologies — delivering the right balance of quality, reliability, and cost.

Custom TFT Display Options

Standard 7inch

Custom FPC

Custom Backlight

Custom Open Frame

Custom Touchscreen Display Options

Standard CTP

Custom Cover Lens

Custom Surface Treatment

Bonding Solution

Front View

Back View

FAQ about Custom TFT Displays and Touchscreen Displays

1. What Custom TFT Display / Custom Touchscreen Displays Options Are Available?

Rocktech offers semi-customization solution including interface, FPC, backlight, open frame, touch screen, cover glass etc.

2. How Much Does It Cost for Custom TFT Display/ Custom Touchscreen Displays?

Tooling charge (NRE) depends on the specific customization requirements from customers.

3. What Is the Minimum Order Quantity (MOQ)?

For custom projects, the typical MOQ during formal MP is 1Kpcs/lot, but it may vary depending on project specifics. We would support a pilot run order with any quantity for a one-time pilot run.

4. What Is the Lead Time for a Custom TFT Display / Custom Touchscreen Displays?

The lead time for custom TFT displays samples generally ranges from 4 to 6 weeks. A detailed delivery schedule will be provided after order confirmation. Expedited options are available upon request.

5. What Are the Steps for the TFT Displays Customization Process?

Our customization process follows these steps:

• Design Approval and Prototyping: After finalizing the design and the drawing is approved by customers, we proceed with sample tooling.

• Sample Testing: If the design revision is required, we support retooling until the sample is formally approved by customers.

• Pilot Run Order after Sample Approval: We support pilot runs without quantity limitations (5 to 500 pieces), but this is offered only one time. This is a special support to help customers verify mass production smoothness and reduce risks.

• Mass Production: After the pilot run, customers must meet our MOQ requirements

6. What Certifications Do Your TFT Displays Have?

Our displays comply with major industry standards, including:

• ISO 9001: Quality Management System

• ISO 14001: Environmental Management System

• RoHS : Restriction of Hazardous Substances

• REACH : Registration, Evaluation, Authorization, and Restriction of Chemicals

7. How Do You Ensure Quality Control for Custom TFT Display / Custom Touchscreen Displays?

We implement strict quality control measures at every stage of production:

• Incoming Material Inspection :Ensuring all raw materials meet required standards.

• In-Process Quality Checks : Monitoring during production to detect issues early.

• Final Product Testing : Conducting functional, reliability, and environmental tests.

• 100% Visual Inspection : Checking each unit for defects before shipment.

Need Linux configuration examples for Rocktech displays? Visit our GitHub repository for device tree & kernel code samples.

Detailed Customization Options for TFT Displays

Standard 7-Inch IPS TFT Display Module

Rocktech Standard 7-Inch IPS Display
P/N: RK070CU01
Interface: LVDS
Brightness: 350 nits
The other custom displays are designed based on this standard IPS display as a foundation.

Rocktech Standard 7-Inch IPS Display RK070CU01 Front View — Standard 7-Inch IPS Display RK070CU01 - Front View

Rocktech Standard 7-Inch IPS Display RK070CU01 Back View — Standard 7-Inch IPS Display RK070CU01 - Back View

Custom TFT Display Flexible Printed Circuit (FPC)

Rocktech offers flexible printed circuit (FPC) customization, allowing modifications in size, shape, pinout, interface type, and length to ensure seamless integration into your application. Our custom FPC solutions enhance connectivity, simplify assembly, and improve design flexibility.
Custom Pin Configuration - Adjust pin number and layout to match your system
Flexible Pitch Options - Standard and custom pitch sizes available
Different Interface Types - LVDS, MIPI, RGB, SPI, and more
Length and Shape Customization - Tailored to fit specific product enclosures
FPC spec in the picture are:
Pin number: 40
Pitch: 0.50mm
FPC Length: 80.66mm instead of standard 47.28mm

Rocktech Custom TFT Display Flexible Printed Circuit FPC - Back View — Custom TFT FPC base on Rocktech Standard 7-Inch IPS Display RK070CU01 - Back View

Custom TFT Display Backlight Solutions

Rocktech offers custom backlight solutions, enabling adjustments in luminance, thickness, and structure to meet the specific requirements of your application. Whether you need a high-brightness display for an outdoor environment or a slim design for compact devices, we deliver the perfect solution.
Luminance Adjustment - Brightness options from 200 to 1500 nits, suitable for indoor and outdoor use
Custom Thickness - Tailored backlight design to fit space-constrained applications
Extended Lifetime - High-quality LED technology for long-term reliability
Product spec in picture are:
Brightness: 1000 nits instead of standard 350 nits
TFT thickness: 5.70mm instead of standard 2.80mm

Rocktech Custom TFT Display Backlight - Front View of RK070CU01H 7-Inch IPS Display — Custom Backlight applied to Rocktech Standard 7-Inch IPS Display RK070CU01H - Front View

RRocktech Custom TFT Display Backlight - Back View of RK070CU01H 7-Inch IPS Display — Custom Backlight applied to Rocktech Standard 7-Inch IPS Display RK070CU01H - Back View

Rocktech Custom Open Frame TFT Display Solutions

Rocktech offers open frame customization service to fit your product structure, ensuring a seamless installation process and final product integration. Designed for ease of installation, flexibility and durability, our open-frame displays are perfect for a wide range of application scenarios.
Customized sizes: Adapt the size and shape of the frame to your product's needs
Easy Installation: Designed for quick and secure mounting with standard custom holes or brackets
Durable design: Rugged frame construction ensures long-lasting performance in industrial environments
Tailored Appearance Custom coatings and finishes are available to complement your product design

Rocktech Custom Open Frame TFT Display - Front View of RK070CU01 7-Inch Industrial IPS Display — Front view of Rocktech Standard 7-Inch Industrial IPS Display (RK070CU01) with custom open frame solution

Rocktech Custom Open Frame TFT Display - Back View of RK070CU01 7-Inch Industrial IPS Display — Back view of Rocktech Standard 7-Inch Industrial IPS Display (RK070CU01) with custom open frame solution

Rocktech Standard 7-Inch Industrial TFT Display with Capacitive Touchscreen (CTP)

Rocktech Standard 7-inch IPS Display with CTP
P/N: RK070CU01-CTG
Resolution: 1024*600 pixels
Interface: LVDS
Brightness: 280 nits after CTP
Touch Solution: GT911 driver IC

Front view of Rocktech Standard 7-Inch Industrial IPS TFT Display with Capacitive Touchscreen (Model: RK070CU01-CTG)

Back view of Rocktech Standard 7-Inch Industrial IPS TFT Display with Capacitive Touchscreen (Model: RK070CU01-CTG)

Rocktech Custom Cover Lens for Industrial TFT-LCD Displays

Rocktech provides fully customizable cover lens, ensuring seamless integration with your product design while enhancing durability and visual appeal. Our solutions support a wide range of modifications to meet specific application requirements.
Custom Sizes & Thickness: Available in various dimensions and thickness options
Irregular-Shaped Cutting: Precision-engineered for unique product designs
Through-Hole Design: Supports button, sensor, and camera cutouts
Gorilla Glass Adoption: Enhanced scratch and impact resistance for rugged applications
Logo & Silkscreen Printing: Personalized branding and functional markings.

Custom Cover Lens Front View for Rocktech 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen — Front view of Rocktech Custom Cover Lens on 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen (Model: RK070CU01-CTG)

Custom Cover Lens Back View for Rocktech 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen — Back view of Rocktech Custom Cover Lens on 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen (Model: RK070CU01-CTG)

Custom Surface Treatments for Rocktech Industrial TFT-LCD Cover Lens

Rocktech offers advanced surface treatment customization to improve display durability, visibility, and user experience.
Our solutions provide product protection against various environmental factors, ensuring optimal performance in a wide range of applications.
Anti-Glare (AG): Reduces screen reflections for better visibility in bright environments.
Anti-Reflection (AR): Enhances optical transmission and minimizes reflections for clearer display performance.
Anti-Fingerprint (AF): Reduces fingerprint smudges and makes the screen easier to clean.
Anti-Shelter: Prevents uneven light distribution and shadow effects to reduce visual disturbances.
Anti-UV: Protects the display from UV damage and fading, extending its life.
Anti-Static: Reduces problems caused by static electricity such as dust attraction and damage to electronic equipment.

Front view of Rocktech Custom Surface Treatment on 7-Inch Industrial TFT-LCD Display with PCAP Touchscreen (Model RK070CU01-CTG) — Front view: Rocktech 7-Inch Industrial TFT-LCD Display with Custom Cover Lens and Projected Capacitive Touchscreen (Model: RK070CU01-CTG)

Back view of Rocktech Custom Surface Treatment on 7-Inch Industrial TFT-LCD Display with PCAP Touchscreen (Model RK070CU01-CTG) — Back view: Rocktech 7-Inch Industrial TFT-LCD Display with Custom Cover Lens and Projected Capacitive Touchscreen (Model: RK070CU01-CTG)

Custom Bonding Solutions for Rocktech Industrial TFT-LCD Displays and Cover Lens

Rocktech supports OCA (Optically Clear Adhesive) bonding technology to improve your display performance by reducing reflections, enhancing brightness, and providing better durability and touch responsiveness. It ensures a high-quality viewing experience even in challenging environments.
Reduced Thickness: Decreased gaps allow for thinner display structures, ideal for applications where space is limited
RImproved Optical Performance:Enhances light transmission to achieve better color accuracy and brightness
RIncreased Durability: Stronger adhesion provides better anti-impact and durability
REnvironmental Protection: Provides improved protection against dust, moisture and UV rays, ideal for outdoor and harsh environments.

Front view of Rocktech RK070CU01-CTG 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen — Front view of Rocktech 7-Inch Industrial TFT-LCD Display (Model: RK070CU01-CTG) with Custom Cover Lens and Capacitive Touchscreen

Back view of Rocktech RK070CU01-CTG 7-Inch Industrial TFT-LCD Display with Capacitive Touchscreen — Back view of Rocktech 7-Inch Industrial TFT-LCD Display (Model: RK070CU01-CTG) with Custom Cover Lens and Capacitive Touchscreen
